    Trojan Batteried Used Electric Golf Carts 4 Seater Curtis Controller

    Ask Lasest Price
    Brand Name : EXCAR
    Model Number : A1S2+2
    Certification : CE
    Price : Negotiate
    Payment Terms : D/A, D/P, Western Union, MoneyGram, L/C, T/T
    Supply Ability : 300 units per month
    Delivery Time : 7 days after received your deposit
    • Product Details
    • Company Profile

    Trojan Batteried Used Electric Golf Carts 4 Seater Curtis Controller

    48V Trojan Battery Electric Golf Cart 4 Seater Curtis Controller Electric Golf Carts


    Basic specification


    Golf cart had become one of our major products in the recent years. Although our monthly output is high, small order is still accepted for this model of golfcart, to facilitate our customers of different kinds.

    The outside cover of this golf cart made of steel, unlike the ones made of FRP, our materials are not easily broken. Even after accidents, this kind of golf cart can be easily fixed.


    Feather of golf cart:


    1.Type sofa chair, comfortable

    2. Efficient Italy graziano driving axle

    3.FR/disc RR/drum, safety golf cart’s higher driving ability

    4.Advanced Disc Brake Technology

    5.USA Imported Unique E-KEY

    6.100% Waterproof accelerator

    7.Special Design Battery Tray


    ItemDescription
    Overall dimensions (L x W x H)3200x1200x2000mm
    Ground clearance150mm
    Wheelbase1670mm
    Front wheel tread (mm)860mm
    Rear wheel tread (mm)970mm

    Key Components


    SystemDC systemAC system
    ControllerCurtis controller 1266A-5201, 275A, imported from USA directlyCurtis controller 1234E-5221, 275A, imported from USA directly
    Motor

    ADC brand Separately excited

    DC motor 48V 3.7kw

    ADC brand Separately excited

    AC motor 48V 5kw

    BatteryTrojan battery, T875,8V*6pcs, imported from USA directlyTrojan battery, T875,8V*6pcs, imported from USA directly
    Transaxle

    Italian GRAZIANO axle

    with gear ration 1:12

    Italian GRAZIANO axle

    with gear ration 1:16

    Charger

    High Frequency onboard charger

    48V/17A regulator

    High Frequency onboard charger

    48V/17A regulator


    Performance


    systemDC systemAC system
    Passenger Capacity44
    Climbing capacity(full load)20%25%
    Max. forward speed23km/h45km/h
    Endurance mileage60-80km80-100km
    Charging time8-10 hours8-10 hours
    Max. loading weight300kgs300kgs
    Min. turning radius2.9m2.9m
    Max. movement after brake at speed of 20km/h≤4m≤4m

    Option Accessories


    ItemOption descriptionItemOption description
    1E-key112-point seatbelt
    2Hinged windshield12Battery water refill system
    3Laminated windshield with wiper13Digital meter
    4Steel brush guard14EM brake
    5Front steel basket15Four wheel disc brake
    6Inner rear view mirror16Carlisle 205/50-10 tyre with10inch wheel
    7Side rear view mirror17Ice box
    8Enclosure18Sand bottle
    9Sunshine cover19Sand rake
    10Golf bag cover20Ball washer

    Color options


    ※ Body Color:White,Black,Beige,Champagene,Dark Green,Red,Metallic Red,Purple,Yellow,Green,Pink,Blue,Dark Blue or made on Panton number

    ※ Seat Color:Black or Beige

    ※ Roof Color:Black,White or Beige


    Product Image



    FAQ


    1.Can you customize the cart according to our special request?

    Yes,we can customize the cart according to your request unless some complex parts we hard to make.


    2.What is your MOQ?

    You can order just 1 unit .But if your order is big, we will provide you with a discount.


    3.Can we put the Logo we designed on the cart?

    Yes, you can put your own Logo on the cart.


    4.What is your lead time for production?

    The typical lead time of our cart is 15 days.


    5.What kind of warranty Excar provides?

    Non-artificial damaged products,shifting for a year or one year repair.


    6. What's your payment term?

    T/T 30% deposit and balance paid before shipment


    Application


    * Golf Course,Hotel,Campus,Park,Airport,Tourist Resorts,Museum,Mountain Area,Wedding Place
