    Ce 2 Seater Electric Golf Car Italy Graziano Axle 48v Trojan Battery

    Ask Lasest Price
    Brand Name : Excar
    Model Number : A1S2/SC
    Certification : CE
    Price : Negotiate
    Payment Terms : L/C, T/T
    Supply Ability : 300 pcs per month
    Delivery Time : about 15 working days
    • Product Details
    • Company Profile

    Ce 2 Seater Electric Golf Car Italy Graziano Axle 48v Trojan Battery

    Ce 2 Seater Electric Golf Car Italy Graziano Axle 48v Trojan Battery



    Features & Benefits


    1. Good aftersale-service, as most parts are manufactured by ourselves;

    2. Has CE certificate for whole carts and for main parts also pass CE, UL, SAA for different carts;

    3. Import main parts: US battery (From USA) and Transaxle (From Italy),Curtis Controller(From USA);

    4. Brake system: Rear wheel Mechanical Drum Brake

    5. Option parts:Full enclosure weather curtains;Split Windshield; 10''Alloy rim and tyre; Caddycooler; Rear&Side mirror; Different colors and option parts;

    6. Good hill climbing ability, the system allows you to customize the car to fit your course;

    7. Smart steering system, easy to make forward and backward;

    8. Good climbing ablity and can park easily on Hills;

    9. Can be easily to be modified to Utility carts.


    Performance


    ItemDescription
    systemDC systemAC system
    Passenger Capacity22
    Climbing capacity(full load)30%35%
    Max. forward speed23km/h45km/h
    Endurance mileage70-90km80-90km
    Charging time8-10 hours8-10 hours
    Max. loading weight360kgs360kgs
    Min. turning radius2.9m2.9m
    Max. movement after brake at speed of 20km/h≤4m≤4m

    * 1) based on the test conditions: 20km/h speed, flat and straight concrete road, wind speed less than 5m/s, temperature of 25 Celsius degree;

    2) Range will vary depending on temperature, grade, payload and driving style.


    Dimensions


    ItemDescription
    Overall dimensions (L x W x H)2921x1219x1727mm
    Ground clearance114mm
    Wheelbase1670mm
    Front wheel tread (mm)860mm
    Rear wheel tread (mm)970mm
    Cargo box dimension800*1100*280mm
    Cargo box materialAluminum

    Electric System


    ItemDescription
    Lights

    48V, LED headlight (includes turning light and position light),

    LED taillights (includes brake lights and turning light),

    HornElectric horn, 48V
    Reverse buzzerElectric, 48V
    Combination switchControl the lights and horn
    Digital Meter (optional)

    Including kilometer indicator, speed indicator, overload indicator, parking brake indicator, clock



    Steering & suspersion


    ItemDescription
    Steering System

    Self-adjusting rack and pinion steering system,

    with automatic compensation function

    Brake SystemRear wheel mechanical brake
    AcceleratorHolzer type, stepless speed change
    Front suspensionMcpherson independent spring suspension
    Rear suspensionCoil spring hydraulic shock absorber
    Driving modelRear axle two stage deceleration, motor direct driving
    Wheel & TyreAlloy wheel & USA Carlisle 18*8.5-8 6 layers

    Packing & Shipping


    Excar golf cart will be packed in steel crate


    ModelDimension(mm)20” container40” container
    A1S2+SCWith roof & windshieldWithout roof & windshieldWith roof & windshieldWithout roof & windshieldWith roof & windshieldWithout roof & windshield
    3400*1200*19003400*1200*12002 units4units6units12units


    Product showroon



    Contact: Pauline Liu
    Dongguan Excellence Golf&Sightseeing Car Co.,ltd
    Mobile: +86-13546943585

    www.excar.com.cn
